Use the Alfen Twin for robust and smart charging in the public domain

Waar te koop?Specificaties

Ev oplaadpuntenPubliekTwin 4xl

EV charging

Benefits Twin 4XL

Cutting-edge and sophisticated smart functions

Smart features for the public space

Designed for integration and maximum charging speed

Advanced technology for today and tomorrow

Made to endure: robust, safe and reliable

Durable, safe and reliable design

Choose and change management system easily

Chose your third party management system provider

The successor to the Twin 4XL is the Twin 5 Plus

If you are looking for a charger that embraces the principles of the AFIR regulation, visit the Twin 5 Plus product page. The Twin 5 Plus charging station by Alfen is future-proofed with ISO 15118 communication capabilities and is prepared for bidirectional power transfer, ensuring compatibility with emerging technologies and evolving industry standards.

Go to Twin 5 Plus product page

A dual socket, with advanced smart functionality including ISO 15118, to withstand the streetscape environment

The Twin 4XL is designed for a high volume streetscape environment and suitable for any semi-public or public space with a 3-phase supply. It offers two back-to back sockets. The Twin 4XL has a vandal-proof steel pillar with a curved top surface so waste cannot be left on the charger. The pillar can be brand wrapped if required. The charger incorporates an RFID reader and MID-meter for financial settlement. Its user interface is language-agnostic, with user instructions in icon form and LED charging status lights. Internet connection is via LTE/Ethernet, with data available via the chosen third party management system provider.

Twin 4XL

Specificaties

- European A-quality: a robust and high-performance product
- Charging speed: Triple phase, 11kW or 22kW
- Dual socket configuration (Type 2)
- Ideal for semi- and public environments such as offices, retail, city centers and parking areas
- Four clear color LEDs with charging status icons
- Housing dimensions: 1385 x 335 x 220mm
- Weight: Approximately 40 kg
- Supports dynamic load balancing for optimized power distribution
- MID-certified energy meter for billing and consumption tracking
- SIM-lock free for flexible charging service provider choice
- Meets international standards (IEC 61851:2017) and includes RCDs for safety
- Complies with all relevant standards and contains comprehensive safety components
- Insight into charging data and automatic settlement of electricity possible
- Identification with charge card or via CPMS
- Durable and vandal-resistant steel construction
- Language independent: control panel with icons
